Use as a plug-and-play switch or use the configuration utility for simple setup.
- 5 ports deliver up to 2000 Mbps bi-directional bandwidth on each port.
- Quality of Service (QoS) for prioritizing network traffic.
- Virtual LAN (VLAN) support for network segmentation and security.
- Troubleshoot connection problems via cable test.
- Port mirroring.
- Bandwidth management to avoid network congestions.
- Network traffic monitoring.
- Broadcast storm control.
Data transmission
|
|
| Jumbo Frames support | |
| MAC address table | 8000 entries |
| Number of multicast groups filtered | 128 |
| Number of VLANs | 64 |
| Switching capacity | 10 Gbit/s |
Design
|
|
| Certification | CE,CSA (CSA 22.2 #950) UL (UL 1950)/cUL IEC 950/EN 60950 FCC Part 15, VCCI, EN55022 (CISPR 22), C-Tick, EN50082-1, EN55024, CCC |
| Colour of product | Grey |
| LED indicators | |
| Rack mounting | - |
Management features
|
|
| Multicast support | |
| Quality of Service (QoS) support | |
| Switch layer | L2/L3 |
| Switch type | Managed |
Networking
|
|
| 10G support | |
| Broadcast storm control | |
| DHCP client | |
| Flow control support | |
| Full duplex | |
| IGMP snooping | |
| Networking standards | IEEE 802.1p,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| Port mirroring | |
| VLAN support | |
Performance
|
|
| Stackable | |
Ports & interfaces
|
|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-T,10BASE-T |
| SFP ports quantity | - |
| SFP+ ports quantity | - |
Power
|
|
| Energy Star certified | - |
| Power consumption (typical) | - W |
Power Over Ethernet (PoE)
|
|
| Power over Ethernet (PoE) Support | |
Operational conditions
|
|
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 0 - 90 % |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -20 - 70 °C |
Packaging data
|
|
| Quick Start Guide | |
Weight & dimensions
|
|
| Depth | 101 mm |
| Height | 26 mm |
| Weight | 270 g |
| Width | 94 mm |
