Bandwidth
|
|
| Data transfer rate (max) | - Mbit/s |
| Full duplex | |
Design
|
|
| LED indicators | Activity,Link |
Networking
|
|
| Chipset | Realtek - RTL8111E |
| Ethernet LAN | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Flow control support | |
| Jumbo frames | 9000 |
| Jumbo Frames support | |
| Networking standards | IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x |
| VLAN tagging | |
Ports & interfaces
|
|
| Connectivity Technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Host interface | Mini PCI Express |
| Interface | Ethernet |
| Internal | |
Certificates
|
|
| Certification | CE, FCC |
| RoHS compliance | |
Operational conditions
|
|
| Operating relative humidity (H-H) | 5 - 95 % |
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -20 - 85 °C |
Packaging content
|
|
| Drivers included | |
| Low-profile bracket | |
| Manual | |
| Number of products included | 1 pc(s) |
Weight & dimensions
|
|
| Depth | 51 mm |
| Height | 8 mm |
| Package depth | 142 mm |
| Package height | 31 mm |
| Package weight | 150 g |
| Package width | 172 mm |
| Weight | 6 g |
| Width | 30 mm |
