Essentials
- Product CollectionIntel® Xeon® Processor E5 v4 Family
- Code NameProducts formerly Broadwell
- Vertical SegmentServer
- Processor NumberE5-2630V4
- StatusLaunched
- Launch DateQ1'16
- Lithography14 nm
Performance
- # of Cores10
- # of Threads20
- Processor Base Frequency2.20 GHz
- Max Turbo Frequency3.10 GHz
- Cache25 MB SmartCache
- Bus Speed8 GT/s QPI
- # of QPI Links2
- TDP85 W
- VID Voltage Range0
Memory Specification
- Max Memory Size (dependent on memory type)1.54 TB
- Memory TypesDDR4 1600/1866/2133
- Max # of Memory Channels4
- Max Memory Bandwidth68.3 GB/s
- Physical Address Extensions46-bit
- ECC Memory Supported ‡Yes
Expansion Options
- Scalability2S
- PCI Express Revision3.0
- PCI Express Configurations ‡x4, x8, x16
- Max # of PCI Express Lanes40
Package Specification
- Sockets SupportedFCLGA2011-3
- Max CPU Configuration2
- TCASE74°C
- Package Size45mm x 52.5mm
- Low Halogen Options AvailableSee MDDS
